Text to Image Python Generation Pipeline

Examples in this folder showcase inference of text to image models like Stable Diffusion 1.5, 2.1, LCM. The application doesn't have many configuration options to encourage the reader to explore and modify the source code. For example, change the device for inference to GPU. The sample features openvino_genai.Text2ImagePipeline and uses a text prompt as input source.

There are several sample files:

Users can change the sample code and play with the following generation parameters:

  • Change width or height of generated image
  • Generate multiple images per prompt
  • Adjust a number of inference steps
  • Play with guidance scale (read more details)
  • (SD 1.x, 2.x; SD3, SDXL) Add negative prompt when guidance scale > 1
  • (SDXL, SD3, FLUX) Specify other positive prompts like prompt_2
  • Apply multiple different LoRA adapters and mix them with different blending coefficients
  • (Image to image and inpainting) Play with strength parameter to control how initial image is noised and reduce number of inference steps

[!NOTE]
OpenVINO GenAI is written in C++ and uses CppStdGenerator random generator in Image Generation pipelines, while Diffusers library uses torch.Generator underhood. To have the same results with HuggingFace, pass manually created torch.Generator(device='cpu').manual_seed(seed) to Diffusers generation pipelines and openvino_genai.TorchGenerator(seed) to OpenVINO GenAI pipelines as value for generator kwarg.

Download and convert the models and tokenizers​

The --upgrade-strategy eager option is needed to ensure optimum-intel is upgraded to the latest version.

Install ../../export-requirements.txt to convert a model.

pip install --upgrade-strategy eager -r ../../export-requirements.txt
optimum-cli export openvino --model dreamlike-art/dreamlike-anime-1.0 --task stable-diffusion --weight-format fp16 dreamlike_anime_1_0_ov/FP16

Run text to image​

Install deployment-requirements.txt via pip install -r ../../deployment-requirements.txt and then, run a sample:

python text2image.py ./dreamlike_anime_1_0_ov/FP16 "cyberpunk cityscape like Tokyo New York with tall buildings at dusk golden hour cinematic lighting"

Examples​

Prompt: cyberpunk cityscape like Tokyo New York with tall buildings at dusk golden hour cinematic lighting

Run with callback​

You can also add a callback to the text2image.py file to interrupt the image generation process earlier if you are satisfied with the intermediate result of the image generation or to add logs.

Please find the template of the callback usage below.

pipe = openvino_genai.Text2ImagePipeline(model_dir, device)

def callback(step, num_steps, latent):
   print(f"Image generation step: {step + 1} / {num_steps}")
   image_tensor = pipe.decode(latent) # get intermediate image tensor
   if your_condition: # return True if you want to interrupt image generation
      return True
   return False

image = pipe.generate(
   ...
   callback = callback
)

Run with optional LoRA adapters​

LoRA adapters can be connected to the pipeline and modify generated images to have certain style, details or quality. Adapters are supported in Safetensors format and can be downloaded from public sources like Civitai or HuggingFace or trained by the user. Adapters compatible with a base model should be used only. A weighted blend of multiple adapters can be applied by specifying multiple adapter files with corresponding alpha parameters in command line. Check lora_text2image.py source code to learn how to enable adapters and specify them in each generate call.

Here is an example how to run the sample with a single adapter. First download adapter file from https://civitai.com/models/67927/soulcard page manually and save it as soulcard.safetensors. Or download it from command line:

wget -O soulcard.safetensors https://civitai.com/api/download/models/72591

Then run lora_text2image.py:

python lora_text2image.py ./dreamlike_anime_1_0_ov/FP16 "curly-haired unicorn in the forest, anime, line" soulcard.safetensors 0.7

The sample generates two images with and without adapters applied using the same prompt:

  • lora.bmp with adapters applied
  • baseline.bmp without adapters applied

Check the difference:

With adapterWithout adapter

Run text to image with multiple devices​

The heterogeneous_stable_diffusion.py sample demonstrates how a Text2ImagePipeline object can be created from individual subcomponents - scheduler, text encoder, unet, & vae decoder. This approach gives fine-grained control over the devices used to execute each stage of the stable diffusion pipeline.

The usage of this sample is:

heterogeneous_stable_diffusion.py [-h] model_dir prompt [text_encoder_device] [unet_device] [vae_decoder_device]

For example:

python heterogeneous_stable_diffusion.py ./dreamlike_anime_1_0_ov/FP16 'cyberpunk cityscape like Tokyo New York with tall buildings at dusk golden hour cinematic lighting' CPU NPU GPU

The sample will create a stable diffusion pipeline such that the text encoder is executed on the CPU, UNet on the NPU, and VAE decoder on the GPU.

Run image to image pipeline​

The image2mage.py sample demonstrates basic image to image generation pipeline. The difference with text to image pipeline is that final image is denoised from initial image converted to latent space and noised with image noise according to strength parameter. strength should be in range of [0., 1.] where 1. means initial image is fully noised and it is an equivalent to text to image generation. Also, strength parameter linearly affects a number of inferenece steps, because lower strength values means initial latent already has some structure and it requires less steps to denoise it.

To run the sample, download initial image first:

wget -O cat.png https://huggingface.co/datasets/huggingface/documentation-images/resolve/main/diffusers/cat.png

And then run the sample:

python image2image.py ./dreamlike_anime_1_0_ov/FP16 'cat wizard, gandalf, lord of the rings, detailed, fantasy, cute, adorable, Pixar, Disney, 8k' cat.png

The resuling image is:

Note, that LoRA, heterogeneous execution and other features of Text2ImagePipeline are applicable for Image2ImagePipeline.

Run inpainting pipeline​

The inpainting.py sample demonstrates usage of inpainting pipeline, which can inpaint initial image by a given mask. Inpainting pipeline can work on typical text to image models as well as on specialized models which are oftenly named space/model-inpainting, e.g. stabilityai/stable-diffusion-2-inpainting.

Such models can be converted in the same way as regular ones via optimum-cli:

optimum-cli export openvino --model stabilityai/stable-diffusion-2-inpainting --weight-format fp16 stable-diffusion-2-inpainting

Let's also download input data:

wget -O image.png https://raw.githubusercontent.com/CompVis/latent-diffusion/main/data/inpainting_examples/overture-creations-5sI6fQgYIuo.png

wget -O mask_image.png https://raw.githubusercontent.com/CompVis/latent-diffusion/main/data/inpainting_examples/overture-creations-5sI6fQgYIuo_mask.png

And run the sample:

python inpainting.py ./stable-diffusion-2-inpainting 'Face of a yellow cat, high resolution, sitting on a park bench' image.png mask_image.png

The resuling image is:

Note, that LoRA, heterogeneous execution and other features of Text2ImagePipeline are applicable for InpaintingPipeline.

benchmarking sample for image generation pipelines​

This benchmark_image_gen.py sample script demonstrates how to benchmark text to image / image to image / inpainting pipeline. The script includes functionality for warm-up iterations, generating image, and calculating various performance metrics.

The usage of this sample is:

python benchmark_image_gen.py [OPTIONS]

Options:

  • -t, --pipeline_type: Pipeline type: text2image/image2image/inpainting.
  • -m, --model: Path to the model and tokenizers base directory.
  • -p, --prompt (default: "The Sky is blue because"): The prompt to generate text.
  • -nw, --num_warmup (default: 1): Number of warmup iterations.
  • -n, --num_iter (default: 3): Number of iterations.
  • -d, --device (default: "CPU"): Device(s) to run the pipeline with.
  • -w, --width (default: 512): The width of the output image.
  • -ht, --height (default: 512): The height of the output image.
  • -is, --num_inference_steps (default: 20): The number of inference steps.
  • -ni, --num_images_per_prompt (default: 1): The number of images to generate per generate() call.
  • -o, --output_dir (default: ""): Path to save output image.
  • -i, --image: Path to input image.
  • -mi, --mask_image: Path to the mask image.
  • -s, --strength: Indicates extent to transform the reference image. Must be between 0 and 1.
  • `-r, --reshape': Reshape pipeline before compilation. This can improve image generation performance.

For example:

python benchmark_image_gen.py -t text2image -m dreamlike_anime_1_0_ov/FP16 -n 10 -d CPU

Performance output:

[warmup-0] generate time: 85008.00 ms, total infer time:84999.88 ms
[warmup-0] text encoder infer time: 98.00 ms
[warmup-0] unet iteration num:21, first iteration time:4317.94 ms, other iteration avg time:3800.91 ms
[warmup-0] unet inference num:21, first inference time:4317.71 ms, other inference avg time:3800.61 ms
[warmup-0] vae encoder infer time:0.00 ms, vae decoder infer time:4572.00 ms

[iter-0] generate time: 84349.00 ms, total infer time:84340.97 ms
[iter-0] text encoder infer time: 76.00 ms
[iter-0] unet iteration num:21, first iteration time:3805.63 ms, other iteration avg time:3799.68 ms
[iter-0] unet inference num:21, first inference time:3805.42 ms, other inference avg time:3799.38 ms
[iter-0] vae encoder infer time:0.00 ms, vae decoder infer time:4472.00 ms

[iter-1] generate time: 84391.00 ms, total infer time:84384.36 ms
[iter-1] text encoder infer time: 78.00 ms
[iter-1] unet iteration num:21, first iteration time:3801.15 ms, other iteration avg time:3802.17 ms
[iter-1] unet inference num:21, first inference time:3800.93 ms, other inference avg time:3801.87 ms
[iter-1] vae encoder infer time:0.00 ms, vae decoder infer time:4468.00 ms

[iter-2] generate time: 84377.00 ms, total infer time:84366.51 ms
[iter-2] text encoder infer time: 76.00 ms
[iter-2] unet iteration num:21, first iteration time:3783.31 ms, other iteration avg time:3802.25 ms
[iter-2] unet inference num:21, first inference time:3783.09 ms, other inference avg time:3801.82 ms
[iter-2] vae encoder infer time:0.00 ms, vae decoder infer time:4471.00 ms

Test finish, load time: 9356.00 ms
Warmup number:1, first generate warmup time:85008.00 ms, infer warmup time:84999.88 ms
Generate iteration number:3, for one iteration, generate avg time: 84372.34 ms, infer avg time:84363.95 ms, all text encoders infer avg time:76.67 ms, vae encoder infer avg time:0.00 ms, vae decoder infer avg time:4470.33 ms
